STM32F745IET6
IC MCU 32BIT 512KB FLASH 176LQFP
The STMicroelectronics STM32F745IET6 is a 32-bit ARM Cortex-M7 microcontroller featuring a single-core processor operating at 216MHz. This device offers 512KB of FLASH program memory and 320KB of RAM. Connectivity options include CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, SAI, SD, SPDIF-Rx, SPI, UART/USART, and USB OTG. Integrated peripherals include DMA, I2S, PWM, and WDT, along with brown-out detect/reset and POR capabilities. Data conversion is supported by 24x12-bit ADCs and 2x12-bit DACs. The STM32F745IET6 is housed in a 176-LQFP package, suitable for surface mounting, and operates within a temperature range of -40°C to 85°C. This component is widely adopted in industrial automation, automotive, and consumer electronics applications.
Additional Information
- Series:
- STM32F7
- RoHS Status:
- ROHS3 Compliant
- Manufacturer Lead Time:
- 52 week(s)
- Product Status:
- Active
- Packaging:
- Tray
- Datasheet:
Technical Details:
| Packaging | Tray |
|---|---|
| Package / Case | 176-LQFP |
| Mounting Type | Surface Mount |
| Speed | 216MHz |
| Program Memory Size | 512KB (512K x 8) |
| RAM Size | 320K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | ARM® Cortex®-M7 |
| Data Converters | A/D 24x12b; D/A 2x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 1.7V ~ 3.6V |
| Connectivity | CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, SAI, SD, SPDIF-Rx, SPI, UART/USART, USB OTG |
| Peripherals | Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT |
| Supplier Device Package | 176-LQFP (24x24) |
| Number of I/O | 140 |
| Programmable | Not Verified |
